Key Features

• Two Switch Types Optional: Works with rocker switches or reset switches, adaptable to different home setups.

• Relay Status Settable: Choose whether the device powers on/off after electricity returns, or maintain the last state.

• Switch State Synchronous: Supports double control with two matched rocker switches; can set flip‑to‑change or synchronous state.

• Multi‑Control Association: Enables double or multiple control of one light via app settings, without rewiring.

• Versions Available: 1‑gang (controls one switch) and 2‑gang (controls two switches).

• ZigBee Gateway Requirement: Needed for ZigBee version modules to connect with the app.

Technical Specifications

• Model: ZM‑104‑M

• Wireless Protocol: ZigBee 3.0

• Voltage: 90–250V AC, 50/60Hz

• Current: 10A per gang, total 10A

• Operating Temperature: –10℃ to 65℃

• Case Temperature: Max +80℃

• Operation Range: ≤70m

• Dimensions: 40 × 40 × 18 mm

• IP Rating: IP20

Package Contents

• 1 × Switch Module
